سنسور ضد انفجار گاز General Monitors , H2S

Sensor Specifications

P/No.: 51457-5

50457-9

Type: Metal Oxide Semiconductor (MOS)

Response
:Time

:With wire screen flame arrestor
T₅₀<14seconds

 With sintered stainless steel flame
  :arrestor
T₅₀<30seconds

 On application of full scale gas
according to ANSI/ISA-92.0.01

:Temperature

:Range

 CSA: -40°F to +167°F
(-40°C to +75°C)

 FM: -40°F to +140°F
(-40°C to +60°C)

 ATEX / IECEx: -40°F to +248°F
(-40°C to +120°C)

Life: 3 - 5 years

Electrical

Classification: Class I, Div. 1, Groups B, C, and D;Ex d IIC
